Faro Focus S120 3D Laser Scanner

Faro Focus S120 3D Laser Scanner
The Faro Focus 3D S 120 is a high-quality laser scanner designed and manufactured by Faro in the United States. This unit includes the necessary software for scene litigation, making it a valuable tool for business and industrial applications, such as levels and surveying. With the Faro Focus 3D S 120, users can expect accurate and efficient measurements and inspections in various settings.

Faro Focus 3D S 120 – Scene Lt Software Included

Specifications

General

• Power supply voltage: 19V (external supply), 14.4V (internal battery)
• Power consumption: 40W and 80W respectively (while battery charges)
• Battery life: Up to 5 hours
• Ambient temperature: 5° – 40°C
• Humidity: Non-condensing
• Cable connector: Located in scanner mount

Deflection unit

• Vertical field of view: 300°
• Horizontal field of view: 360°
• Vertical step size: 0.009° (40,960 3D pixels on 360°)
• Horizontal step size: 0.009° (40,960 3D pixels on 360°)
• Max. vertical scan speed: 5,820rpm or 97Hz

Laser (Optical transmitter)

• Laser power (cw Ø): 20mW (Laser class 3R)
• Wavelength: 905nm
• Beam divergence: Typical 0.19mrad (0.011°)
• Beam diameter at exit: 3.0mm, circular

Package Includes

• FARO Focus3D S120 Scanner
• Rechargeable Li-Ion Battery
• Battery Charging Cradle
• AC/DC Power Adapter
• AC Power Cable
• Hex Key Wrench
• Focus3D Quick Start Guide
• Software Manual
• FARO Transport Case
